Hudson Reed Sloane 381 x 1800mm Double Panel Radiator With Mirror

Hudson Reed Sloane HLW64 Details

Finished in white and incorporating a practical mirror, this Sloane Double Panel Radiator by Hudson Reed is a visually appealing radiator that will bring you both warmth and aesthetic appeal. Suitable for wall mount installation, the ultra-modern radiator with squared off edges is supplied with fixing screws and has vertically inclined flat radiator panels for better heating efficiency. This designer radiator comes with a 20-year guarantee from Hudson Reed, so all that you have to do is install it in your home today and enjoy its style and comfort all year through.

Double panel radiator with mirror.
Ultra-modern radiator with squared-off edges.
Size [mm]: 381mm x 74mm x 1800mm [Width x Depth x Height].
Size [cm]: 38.1cm x 7.4cm x 180cm [Width x Depth x Height].
Maximum projection: 120mm (120cm).
Heat output (BTU/hr):@30°C - 1696, @50°C - 3344, @60°C - 4236.
Watts:@30°C - 497, @50°C - 980, @60°C - 1248.
RAL No: White - 9016 and Anthracite 7016.
Suitable for wall mount installation.

Pipe centre for valves: 444mm (44.4cm).
Wall to Centre of tapping: 85mm (8.5cm).
Type of Heat: Water.
After installing any new radiators, when refilling the system, a suitable inhibitor is to be used.
All tappings are 1/2" British Standard Pipe.
Valves shown in the image are not included - sold separately.
Suitable valve available in Compatible Valves tab below [Optional].
Refer to the technical image for detailed technical dimensions.
Download Customer Data Sheet and Installation Instruction PDF File from the Additional Info Section.

Note: It is recommends that the pipework should not be done until the heated towel rail is receipt. Dimension are subjected to minor deviation.

Radiator Calculator

Info / Size (mm)

Radiator
Width: 381 mm
Height: 1800 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: Sloane
⤷ Colour
: White
⤷ Warranty/Guarantee
: 20 Years
⤷ Material
: Steel
⤷ Theme
: Modern
⤷ Installation Type
: Wall Mounted
⤷ Width
: 381
⤷ Projection (Depth)
: 74
⤷ Height
: 1800

⤷ Orientation
: Vertical
⤷ Barcode
: 5055369000661
⤷ BTU Output
: 30°C - 1696 | 50°C - 3344 | 60°C - 4236
⤷ Watts
: 30°C - 497 | 50°C - 980 | 60°C - 1248
⤷ Valves Included
: Sold Separately
⤷ Fuel Type
: Central Heating
⤷ Wall to Centre of Inlet
: 85
⤷ Panel Configuration
: Double

Additional Info & Downloads

Download the Customer Data Sheet Pdf File Download the Installation Instruction Pdf File

Total: £192.16 3-4 Working Days Approx QS Supplies

2 Features Included In This Product Explained

RAL Colours

It refers to a European colour-matching system which defines colours for coatings, paints, and plastics. The colour standard is administrated by the RAL Deutsches Institut für Gütesicherung und Kennzeichnung.
Read more...

Double Panel Radiators

Also known as type 22 radiators, these double panel radiators are constructed using two steel panels and two convectors or sets of fins which emit greater heat output. Its heat output is more than a single panel and will heat up the room much faster. This kind is ideal for larger than average spaces.
