Merlyn 10 Series 1 Door Right-Hand Offset Quadrant Enclosure 1400 x 800mm

Merlyn 10 Series M10148HR Details

Showering not only rejuvenates and reinvigorates you, but it gives you a sensational and thrilling feeling. Experience all that is more within the 10 Series 1 Door Offset Quadrant Enclosure, a luxury offering by Merlyn. The exhilarating unit is made using top quality, toughened safety clear glass, which gives it a classic look. The design has both straight and curved elements, with one straight panel and a curved panel. You can select a Right-handed door or Left hand at your convenience. The glass is Mershield Stayclear easy clean, protected glass with chrome eyelet handle and circular filler plate option. Extra smooth roller action allows for quite closing with minimum effort.

The manufacturing code of this product is M10148HR.
Size [mm]: Width 1400mm x Depth 800mm x Height 2000mm.
Size [cm]: Width 140cm x Depth 80cm x Height 200cm.
Right-handed door.
Left hand optional [See option].
It comes with an eyelet handle with chrome eyelet and a circular filler plate option.
Extra smooth roller action for quiet closing - a quiet glide wheel that softly opens and closes with minimum effort.
20mm adjustment.
Wetroom Adjustment: 1355 - 1375mm, 755 - 775mm [minimum - maximum].

Tray Finish Adjustment: 1375 - 1395mm, 775 - 795mm [minimum - maximum].
Adjustable wall profiles to compensate for out-of-true walls and have micro-adjustment features for fine-tuning to obtain a perfect fit and operating action.
Fully concealed fixings.
UKCA & CE certified product.
The tray and brassware shown in the image are not included.
Manufactured by ISO 9002 and EN 14428and utilises toughened safety glass to EN 12150.
Supplied complete with full installation instructions and the necessary fixings.
Dedicated Tray, Extension Profile, and Enclosure Wiper Optional [See Option].

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Range
: 10-Series
⤷ Handle Finish
: Chrome
⤷ Coating
: Mershield Stay-Clear
⤷ Shape
: Curved
⤷ Warranty/Guarantee
: Lifetime
⤷ Installation Type
: Corner
⤷ Handle Style
: Eyelet Handle
⤷ Waste Included
: Sold Separately
⤷ Width
: 1400
⤷ Depth
: 800
⤷ Configuration
: Door Only
⤷ Height
: 2000
⤷ Barcode
: 5057199409379
⤷ Door Type
: Right
⤷ Frame Design
: Frameless
⤷ Frame / Profile Finish
: Chrome

⤷ Glass Type
: Clear
⤷ Glass Type
: Toughened
⤷ Glass Thickness
: 8
⤷ Glass Thickness
: 8, 10
⤷ Number Of Doors
: 1
⤷ Door Adjustment
: 1355 - 1375 x 755 - 775
⤷ Entry Width
: 340 - 435
⤷ Tray Included
: Sold Separately
⤷ Easy to Clean Glass
: Yes
⤷ Concealed Fixings
: Yes
⤷ Power Shower Proof
: Yes
⤷ Handle Included
: Yes
⤷ Wetroom Compatible
: Yes
⤷ Tray Compatible
: Yes
⤷ Door Opening
: Left / Right

Additional Info & Downloads

Download the Technical Specification Of Tray Pdf File Download the Installation Instruction Pdf File

Customise Your Product

Quadrant Tray

Dedicated, Strong and Tough Shower Tray, specially manufactured for this shower quadrant. Please Note: The image is for illustration purposes only.

None
OP-83737 - 1400 x 800mm Right Hand - S148QR + £282.80
OP-83738 - 1400 x 800mm Left Hand - S148QL + £282.80

20mm Extension Profile For Series 10

Extension profile for extra 20mm adjustment! Please note: The image is for illustration purposes only.

None
OP-44510 - Extension Profile Chrome - M108EXTQU + £85.93

Merlyn Shower Wiper

Merlyn Shower Wiper and Chrome holder available for Merlyn Enclosures. Please note image is for illustration purpose only.

None
OP-44516 - Shower Wiper With Chrome Holder + £49.37

Total: £1689.77 2-3 Working Days Approx QS Supplies

7 Features Included In This Product Explained

Mershield Stayclear Coating

All Merlyn Series range products are subjected to the Mershield Stayclear glass protection that keeps the glass looking clear. It decelerates the build-up of lime scale and soap deposits, making cleaning an absolute breeze. The coatings' smooth surface does not allow any grime, dirt or water to stick easily, keeping it pristine.

Toughened Safety Glass

Toughened glass, tempered or safety glass as it is rightly called, is five times harder than regular glass of the same size and thickness, which makes it so that it won’t break as easily. It also shatters with scattering as it tends to break into tiny, blunt pieces without harming anyone nearby. Known to have greater thermal strength, this durable material with double glazing has almost twice the soundproofing abilities and provides excellent heat insulation.

Adjustable Wall Profile

These refer to the pieces of material that fit the shower door or panel against a wall and can be adjusted to allow for out-of-true walls for a neat and seamless installation. The ability to adjust the side profile gives a perfect fit and makes the installation process easy. Depending on the manufacturer, the profile can be adjusted between 12 to 30mm.

UKCA Great Britain Mark

Merlyn enclosures now carry the UKCA mark, which stands for UK Conformance Assessment. This mark indicates that the product meets or exceeds GB-designated standards. The UKCA mark is now the standard labelling for products sold in Great Britain (England & Wales & Scotland).

CE Certified Product

CE mark meets the prescribed safety, health and environmental protection requirements and all appropriate EU requirements. This mark is mandatory for products designed, made and sold in the European Economic Area.

Concealed Fixing

Concealed fixings provide a method of installation where screws and brackets are hidden from view. This offers a clean, uncluttered look and enhances the overall aesthetic of the bathroom.

Frameless

As the name implies, shower doors or bath screens with minimal framing in the design are called frameless. As the enclosure is mostly glass, it can offer a clear view into your shower to highlight features that need attention, such as tiling, shower columns or other components. Aesthetically stunning, these are generally made of very thick safety glass.

Questions & Answers

Submit Your Questions 2 Questions Answered

Have a question about this item? Ask our technical team. We aim to reply within 72 hours.

Jeremy Asked :
Hi, can you tell me where the waste outlet is in the left-handed 1400 x 800 tray?

Answered By QS Team

Please see the attached layout drawing showing the waste positions of the tray.

Was this answer helpful?

Jon Asked :
We are looking for a 1400 x 800 shower enclosure and a Merlyn 10 Series 1 Door Offset Quadrant Enclosure that you sell seems to fit the bill. Can you tell me how the glass is sealed onto the tray? Is there a lip, or is silicone the only seal? (I am not a great fan of silicone alone).

Answered By QS Team

The fixed panels are sealed using silicone, and there is a luna rail which sits on the tray on the outside of the sliding door. Please look at the Installation Instructions PDF file from the Additional Info section of the product for more details.
