Franke Largo Designer Pack LAX 110 50-41 Stainless Steel Sink And Tap

QS-V30041 MFC CODE: 1220250208


RRP: £551.52 You Save £165.46 on RRP

4.0 out of 5

3 out of 3 customers rated 80%

Review this Product


2 to 3 Weeks

Shipping: £6.99


Franke Largo Bowl Sink and Olympus Tap Designer Pack the perfect duo in your kitchen bring great looks and performance. Amazing silk finish on the sink and is fabricated from nickel steel that is stain, rust and corrosion resistant. The twin-lever, chrome finish tap which is part of the kit has a graceful curved spout. It is fitted with ceramic valve and requires low water pressure system.

+  Read what's included.. & options available

Download the Installation Guide Pdf File
Download the Installation Guide Pdf File

Please Note all the measurements are in 'mm'
Colour Silk
Installation/Style Undermount
Number of Bowls 1
Overall Length 530
Overall Width 440
Minimum Base Unit Size Required 600
Length of Main Bowl 500
Width of Main Bowl 410
Depth of Main Bowl 175
Cut-Out Length 497
Cut-Out Width 407
Cut-Out Template PDF Supplied Yes
Material Stainless Steel
Tap Included Yes
Plumbing Kit Sold Separately
Compatible With Optional Waste Disposal Unit Yes
Overflow Type Patented Hygienic
Waste Included Yes
Waste Type Basket Strainer
Warranty/Guarantee 50 Years

INFO / SIZE (mm)

  • Tap
  • Pipe Centre: 220
  • Sink
  • Length: 530
  • Width: 440



  • Manufacturing code of this Designer Pack [Specialist Range] is 122.0250.208, 115.0049.980
  • Guarantee from Franke: 50 years on sink, 5 years on taps moving parts, 1 year on coating and finish against any manufacturing defects
  • 1.0 Bowl Sink Details:
  • Silk finish
  • Cabinet Size: 600mm, denotes the measurement which the bowl need to fit into
  • Overall Size is - Length 530mm x Width 440mm
  • Size of bowl is - Length 500mm x Width 410mm x Depth 175mm
  • Granite worktop and rollamat shown in the image are not included
  • Incorporated with basket strainer waste and patented hygienic overflow [easy to clean by removing the logo plate - shows the overflow aperture]
  • Fabricated from nickel steel [stain, rust and corrosion resistant]
  • Undermount installation [Installed underneath the worktop and is only compatible with solid surface worktop such as granite or solid wood]
  • Cut-Out Size is - Length 497mm x Width 407mm - Download cut-out template PDF from technical tab
  • Olympus Mixer Tap Details:
  • Chrome finish
  • Twin lever operation
  • Bi-flow spout
  • Size: Width 170mm x Height 390mm
  • Centre of Inlet to Centre of Outlet : 220mm
  • Fitted with ceramic disc valve
  • Requires low water pressure system [delivers at least 4 litres per minute of hot water at 0.3 bar pressure]
  • Plumbing Kit [See Option]
  • Tap Brace [See Option]
  • Turbo Plus TP-75 Waste Disposal Unit Compatible [See Option]
  • Accessories [See Option]


Olympus Tap

Olympus Tap

Sink comes with the Olympus Tap in chrome finish as included, although you can upgrade the tap to various options.

Siphon Plumbing Kit

Siphon Plumbing Kit

It is the perfect plumbing solution and have a manifold with an incline and an air vent for faster water disposal. Made of rigid grey polypropylene, these kit is the hygienic solution to a Franke waste system.

Tap Brace

Tap Brace

Franke has developed an innovative patented new tap brace for large or heavy taps, which may require additional support when fitted to a stainless steel sink. A perfect solution to the occasional problem of flexing.

Waste Disposal Unit

Waste Disposal Unit

Free kitchen from unsightly and unhygienic organic household waste. Magnet motor of this unit reach high speed in a split second, whilst running water through the unit, food waste is liquefied into fine particles and easily flushed through the pipework.



Accessories for kitchen sinks. Please note image shown is for illustration purpose only.



Light weight and multi-purpose Rollamat from Franke can be used as a drainer or for keeping hot pans on any worktop. Easy to clean and rolled up, this rollamat is crafted from stainless steel rod with rubber ends on both side and perfectly sits on drainer
