Heritage Dawlish Exposed Thermostatic Chrome Shower Valve With Flexible Riser Kit

Heritage Dawlish SDCDUAL09 Details

The traditional style Exposed Thermostatic Valve from Heritages Dawlish range comes with Slide Rail Kit and is designed for surface installation. It features a single outlet for convenient use with the handset and dual controls - separate for flow and temperature. A maximum temperature setting prevents accidental scalding. It also ensures that your shower maintains a constant temperature, even in the event of the cold water supply failure. Suitable for both low and high water pressure systems, it requires effective operating pressure between 0.2 bar and 5.0 bar. Crafted from durable material it comes in Chrome finish, Vintage Gold finish and Brushed Nickel Finish.

Traditional design.
Feature one outlet [suitable for use with handset].
Dual control - separate control for flow and temperature.
Surface-mounted installation.
Size of the valve [mm]: 152mm x 147mm [Depth x Height].
Size of the valve [cm]: 15.2cm x 14.7cm [Depth x Height].
Height of raiser rail: 710mm [71cm].
Inlet connection: 15mm compression.

Outlet connection: G 1/2 inch.
Thermostatic temperature control and automatic stop prevent hot or cold water surges.
Adjustable inlet centres, allowing you to use existing pipework with centres measuring anything between 136mm and 158mm.
Designed in the UK by expert engineers, they can operate effectively even at low pressure, making them suitable for all water systems.
Recommended for smooth working is 0.2 bar [LP-Low Pressure], and the maximum is 5.0 bar.
Plumbing system suitability: all - ideally balanced.
For complete size details, please refer to the technical drawing.
Download installation instructions and product data sheet PDF file from the additional info section.

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 5 Years
⤷ Material
: Brass
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Exposed
⤷ Inlet Centres
: 136-158
⤷ Minimum Operating Pressure (Bar)
: 0.1
⤷ Hose Included
: Yes
⤷ Spray Setting
: 1

⤷ Flow Rates (l/min)
: 0.1 Bar - 6.5, 0.5 Bar - 10.2, 1 Bar - 14.5, 2 Bars - 20.5, 3 Bars - 25.1, 5 Bars - 32.4
⤷ Configuration
: Valve, Slide Rail And Handset Kit
⤷ Temperature Control
: Thermostatic
⤷ Plumbing System Compatibility
: All
⤷ Separate temperature and power controls
: Yes
⤷ Handset Included
: Yes
⤷ Spray Patterns (Shower Handset)
: Single
⤷ Valve Size
: D 152 x H 147
⤷ Rail Length
: 710

Additional Info & Downloads

Download the Installation Instruction for Shower Kit Pdf File Download the Installation Instruction for Shower Valve Pdf File Download the Product Data Sheet Pdf File

Total: £384.31 5 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Thermostatic Control

Thermostatic shower control works behind the scenes to achieve or maintain water temperature output from a showerhead. With the built-in safety feature, the shower provides a consistent water temperature.
Read more...

1-Outlet

One outlet in a shower system means that hot and cold water flows from a single opening.

High Water Pressure

Water systems operating at 1.0 bar or higher pressure are considered high-pressure systems. Products usually come labelled if they are suitable to use under such pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
