Flova Str8 Diamond Chrome Basin Mixer Tap With Clicker Waste

Flova Str8 STBAS Details

This elegant and gracefully designed Str8 Basin Mixer Tap, from Flova, will certainly make a fashion statement at your wash-up area. The contemporary designed tap is fabricated from high-grade lead-free brass and finished in diamond chrome to provide it with strength and lustre. It is supplied with Neoperl aerator for flawless water flow. Suitable for all plumbing systems and comes with a 10-years guarantee from the company. Get it today, at a never-before price from QS Supplies.

Available in 3 heights - 105mm, 165mm, 255mm.
Single-side lever mixer tap.
Deck mounted.
It comes with slotted clicker waste.
Easy-to-clean diamond chrome finish.
Modern design.
Fitted with 35mm [3.5cm] sedal manual cartridge.
Works with conventional gravity-fed systems.
CE Approved.
Fully compatible with UK plumbing systems.
For complete size details, please refer to the technical drawing.

Specifications Of 105mm Height Tap.
Centre of the inlet to centre of outlet: 100mm [10cm].
The minimum water pressure Recommended for smooth working is 0.2 bar [LP-Low Pressure].
Specifications Of 165mm Height Tap.
Centre of the inlet to centre of outlet: 120mm [12cm].
The minimum water pressure Recommended for smooth working is 0.5 bar [MP-Medium Pressure].
Convert to low pressure by using this low-pressure accessory kit [Sold Separately].
Specifications Of 255mm Height Tap.
Centre of the inlet to centre of outlet:120mm [12cm].
The minimum water pressure Recommended for smooth working is 0.5 bar [MP-Medium Pressure].
Convert to low pressure by using this low-pressure accessory kit [Sold Separately].

Info / Size (mm)

Tap
Pipe Centre: 100 mm

Technical Specifications

Please note all the measurements are in 'mm'

⤷ Water Activation
: By Lifting
⤷ Tap Body Shape
: Square
⤷ Range
: Str8
⤷ Handle Position
: Right
⤷ Colour
: Chrome
⤷ Warranty/Guarantee
: 10 Years
⤷ Material
: Brass
⤷ Theme
: Modern
⤷ Installation Type
: Deck Mounted
⤷ No. of Holes Required
: 1
⤷ Spout type
: Fixed
⤷ Valve Included
: Yes
⤷ Valve/Cartridge Type
: Sedal Cartridge
⤷ Handle Material
: Brass
⤷ Base To Spout
: 105

⤷ Spout Reach
: 100
⤷ Overall Height
: 105
⤷ Max. Deck Thickness
: 45
⤷ Inlet Connections
: 1/2"
⤷ Minimum Operating Pressure (Bar)
: 0.5
⤷ Waste Type
: Clicker
⤷ Flow Rates (l/min)
: 0.5 bar - 2.94
⤷ Handle Style
: Lever
⤷ WRAS Approved
: No
⤷ Deck Mount Drill Hole Diameter
: 35
⤷ Waste Included
: Yes
⤷ Compliance/Approvals/Standard
: CE
⤷ Barcode
: 5057199248107
⤷ Product Type
: Basin Mixer Tap

Customise Your Product

Optional Accessories

Optional accessories are available. Please note image is for illustration purpose only.

None
OP-220248 - Low Pressure Kit - FLLPSPRAYSTD + £14.03

Total: £201.74 5 Working Days Approx QS Supplies

4 Features Included In This Product Explained

Neoperl Aerator

Neoperl aerators are components that perform some critical functions in taps and showers. They control the flow stream's straightness and diameter while reducing splashing by adding air to the stream. This effectively saves water and, thereby, water bills. It is compliant with local plumbing codes and standards.

Suitable For Gravity Fed System

You can use a shower, showerhead or tap with a gravity-fed water system with a hot and cold water feed. Usually found in old properties, these typically have low pressure of water flow.

Medium Water Pressure

Water systems operating at a pressure between 0.5 and 0.9 bar are considered medium pressure. Products usually come labelled if they are suitable for use in medium pressure.

Low Water Pressure

Water systems operating at a pressure between 0.1 and 0.4 bar are considered low pressure. Products usually come labelled if they are suitable to use under such pressure.
